MERRY GO ROUND 4,5 M
MERRY GO ROUND 5M
MERRY GO ROUND 6,5M
MERRY GO ROUND 7 M
MERRY GO ROUND 8,5 M
MERRY GO ROUND 9 M
MERRY GO ROUND 10,5 M
MERRY GO ROUND 12 M
MERRY GO ROUND 15 M
MERRY GO ROUND
A carousel or merry-go-round, is an amusement ride consisting of a rotating circular platform normally supplied with horses much loved by children but for the entertainment of the whole family. Many of which are moved up and down by gear work to simulate galloping. A theme music plays while the amusement ride is moving.
Carousels are commonly populated with horses, but different themes are available and new theme can be developed to meet customer request.
Our Carousel are available in all of this diameter measure:
CAROUSEL 4.5 m
CAROUSEL 5 m
CAROUSEL 6,5 m
CAROUSEL 7 m
CAROUSEL 8,5 m
CAROUSEL 10,5 m
CAROUSEL 11 m
CAROUSEL 12 m
CAROUSEL 14 m
CAROUSEL 15 m”
Technical Data - 4,5 meter type
TECHNICAL DATA
4,5 meter type
Weight: 1.7 t / 16.67 kN
Nr of seats: 20
Hourly capacity: 320 passengers per hour
Revolving Speed: 4 Rpm
Shipping Volume: 1×20’ box
Voltage: 3phase + neutral + earth (230/400/415 V)
Motor power: 2,5 kW
Noise leve: less than 80db
Technical Data - 5 meter type
TECHNICAL DATA
5 meter type
Weight: 44,13 KN/4,5 t (full load 53 KN/5,4t)
Nr of seats: 14-22
Hourly capacity: 280/450 Passengers
Revolving Speed: 4 Rpm
Boarding: Simultaneous
Shipping Volume: 1×20’ box
Voltage: 3phase + neutral + earth (230/400/415 V)
Motor power: 8,5 kW (single motor supply each horses movement)
Noise leve: less than 80db
Technical Data - 6.5 meter type
TECHNICAL DATA
6.5 meter type
Weight: 51 KN / 5.1t (full load 80 KN / 8.16t)
Nr of seats: 20-32
Hourly capacity: 300/480 passengers
Revolving Speed: 3 Rpm
Boarding: Simultaneous
Shipping Volume: 1×40’ box
Voltage: 3phase + neutral + earth (230/400/415 V)
Motor power:
2.2Kw ( Only Rotation)
5.5 standard version (single motor supply each horses movement)
Noise leve: less than 80db
Technical Data - 7 meter type
TECHNICAL DATA
7 meter type
Weight: 63,74KN/6,5t(full load87,27KN/8.9t)
Nr of seats: 20-34
Hourly capacity: 300/480 passengers
Revolving Speed: 3 Rpm
Boarding: Simultaneous
Shipping Volume: 1×40’ box
Voltage: 3phase + neutral + earth (230/400/415 V)
Motor power:
2.2Kw ( Only Rotation)
5.5 standard version (single motor supply each horses movement)
Noise leve: less than 80db
Technical Data - 8.5 meter type
TECHNICAL DATA
8.5 meter type
Weight: 83.35 kN / 8.5t
Nr of seats: 45-55
Hourly capacity: 400/500 passengerss
Revolving Speed: 2 Rpm
Boarding: Simultaneous
Shipping Volume: 1×40’ box
Voltage: 3phase + neutral + earth (230/400/415 V)
Motor power: 3,7 kW
Noise leve: less than 80db
Technical Data - 10.5 meter type
TECHNICAL DATA
10.5 meter type
Weight: 100KN / 10.2t
Nr of seats: 62
Hourly capacity: 650/750 per hour
Revolving Speed: 2 Rpm
Boarding: Simultaneous
Shipping Volume: 2×40’ box
Voltage: 3phase + neutral + earth (230/400/415 V)
Motor power: 4,5 kW
Noise leve: less than 80db
