EQUINOX
The speed of rotation is 23 cycles per minute and its radius is 1700 mm. The passenger unit can accommodate are 18 adult passengers.
On the ride is installed a motorization connected to the slewing ring by 2 cardan shafts, the correct synchronism is guaranteed by a chain connected to the axial rotation.
The passengers unit (gondola) connecting with 2 connecting rod spin with a ascent and descent movement keeping the gondola in the horizontal position.
Technical Data 12 Seats
TECHNICAL DATA 12 SEATS
Weight: 10,3 t-101kN (11,65t – 114,24 kN full load)
Capacity: 12 passengers
Rotation Speed: 23 rpm
Boarding: Simultaneous
Shipping volume: N/A
Voltage: 3phase + neutral + earth (230/400/415 V)
Motive Power: 46 KW
Noise Level less than 80db
Technical Data 18 Seats
TECHNICAL DATA 18 SEATS
Weight: 11,95t-117,19kN (13,3t – 130,43 kN full load)
Capacity: 18 passengers
Rotation Speed: 23 rpm
Boarding: Simultaneous
Shipping volume: N/A
Voltage: 3phase + neutral + earth (230/400/415 V)
Motive Power: 78 KW
Noise Level less than 80db
